Amstrad PowerPage 64


Created on: 07-05-2019  By Gee
I'd seen a while back about desktop publishing software that ran on the CPC range of computers and it made me want to have a go.
At Christmas I was gifted an Amstrad Action cover tape that had lemmings and a few other things on it. One of the few other things was PowerPage 64k version. I never really thought about it much as I was only in the possession of 464 computers and not a 6128 (I owned one but it wasn't with me at the time) and PowerPage required a disc drive to copy the data over to and then run from there.
If we fast forward to last week, My cpc 6128 was dropped off by a mate along with my two colour monitors. I set the 6128 up and had a little play about to check it over. I then set up the cassette input (as I had b... Read More!

    Associated files



Amstrad Controller STL files


Created on: 22-04-2019  By Gee
I mentioned a while back that I was going to share the STL files so you can make the Amstrad controllers at home (if you have a 3d printer). So here they are!
I wanted to make sure I had the correct files as I had made several versions. This was due to testing several things then forgetting to write down which ones were the ones that worked best.
These files MUST NOT be used for making and selling the controllers under any circumstances. The designs are all my own work and belong to me. I am releasing them in good will to help the Amstrad community make their own controllers as they helped me and continue to do so with several things.... Read More!

    Associated files



Amstrad Splitter Cable PCBs


Created on: 17-04-2019  By Gee
Ever since I realised that I could use 2 controllers or joysticks on the Amstrad CPC series, I had to try make some splitters.
A couple of weeks ago I drew up the schematics and then the PCB layout on CAD. Once I was happy with them I had the same company that produced my Controller PCBs make them.
Yesterday I took delivery of them and, they look great. Exactly what I was after, if not better!
Last night, when the little one was finally in bed, I set about soldering up the ports, diodes and the connecting cable that goes to the CPC. I soldered up one side and noticed that I was getting some odd results. The only button that was working when using the splitter was the fire 1 button. Then I found out that If I held down t... Read More!


Amstrad Controller


Created on: 16-04-2019  By Gee
After using my completed controller, I realised pretty soon that it wasn't very comfortable to use.
It worked great, but not very ergonomic. Now rather than redesign the whole thing, I made a surround for it to fall into. I drew it up pretty quick and then printed out a draft to see where I had made any errors. Thankfully, the errors I did make were quite simple and easy to fix. So I set about making another one with the corrections.
After this was all done, I had a great controller! Even if I do say so myself. I realise that it's a bit small, but it works well and is super easy to use.
The first night after it was all put together, the wife sat and had a game of Tetris with me.
I'm looking forward to sitting chi... Read More!


New Datacorder Keys


Created on: 08-04-2019  By Gee
My second CPC 464 was bought with the knowledge that the keys on the datacorder were mostly bust. I wanted to find out a way of making some new ones and thought of all different kinds of ways, Including making some out of wood! That would've looked awesome I think, but I have no wood working skills what so ever. So it'd take me forever just to learn woodworking.
This was until I got my 3d printer. Then that was a simple easy option. I took one of the original, still in tact keys and measured it out. I then drew it up in CAD and printed a couple out. The way that I had the printer make them made them come out rather aweful looking on one side, so I had to have it print upright in a way that took longer, but once it came out it looked ... Read More!
